Compact ejectors.

SAVES UP TO 50 % OF ENERGY

Energy saving function by integrated pressure control

. Handling of dense and porous workpieces
. Within the supply pressure of 4 - 8 bar (58 - 116 psi), the ejector works at 3.5 bar (50.76 psi) with same high performance
. Energy saving increases along with the difference between supply pressure and operating pressure
. Electronic vacuum and blow-off control for short cycle times
. Manual adjustment of the blow-off flow rate using a setscrew
. Very compact design with integrated open silencer
. Dust-resistant design, no additional filters required

SAVES UP TO 90 % OF ENERGY

Double energy efficient by integrated pressure control and electronic air saving function

. Electronic air saving function reduces operating costs by up to 90 % with dense workpieces
. Pressure regulation energy-saving function at constant 3.5 bar (50.76 psi) reduces operating costs by up to 50 % with porous workpieces
- Energy saving increases along with the difference between supply pressure and operating pressure
. Electronic vacuum and blow-off control for short cycle times
. Manual adjustment of the blow-off flow rate using a setscrew
. Very compact design with integrated open silencer
. Dust-resistant design, no additional filters required
. NO - version on request
. Smaller nozzle diameters on request

SAVES UP TO 50 % OF ENERGY

Energy saving function by integrated pressure control

. Handling of dense and porous workpieces
. Within the supply pressure of 4 - 8 bar (58 - 116 psi), the ejector works at 3.5 bar (50.76 psi) with same high performance
. Electronic vacuum and blow-off control for short cycle times
. Manual adjustment of the blow-off flow rate using a setscrew
. Low noise emissions as, starting from 4 bar (58 psi), outlet pressure is independent of inlet pressure
. Open silencer further reduces the noise level and is completely maintenance-free
